Specifications + Dimensions
| AC Output | |
| 5 kW | 60 Hz, 1800 RPM, 1 Ph, 1.0 PF, 120-240 V/25A, 120 V/50A |
| 4.5 kW | 50 Hz, 1500 RPM, 1 Ph, 1.0 PF, 220V/22.7A |
| Voltage Regulation 1 Ph, 1.0 PF, 220 V/22.7A | +/- 5% |
| (Based on 1.0 unity power factor. Deratings: 3% per 1000 ft. over 500 feet above sea level. 1.5% for every 10° over 77°F) |
| Lugger L673L Engine | |
| Type | Vertical 3 cylinder diesel |
| Displacement: | 46.4 in3 (0.76 ltr) |
| Bore/Stroke: | 2.64/2.83 in (67/72 mm) |
| HP @ RPM | 9.9/1800 7.7/1500 |
| Approximate fuel use: | |
| 1800 RPM @ full load | 0.59 gph (2.2 lph) |
| 1800 RPM @ half load | 0.32 gph (1.2 lph) |
| 1500 RPM @ full load | 0.50 gph (1.9 lph) |
| 1500 RPM @ half load | 0.28 gph (1.1 lph) |
| (Actual fuel consumption will vary depending on operating conditions.) | |
| Installation Data | |
| Exhaust Outlet | 1.25 in (32 mm) |
| Fuel inlet and return | 1/4 inch NPT |
| Weight and Height | |
| Length: | 32.8 in (834 mm) |
| Width: | 17.1 in (435 mm) |
| Height: | 26.8 in (650 mm) |
| Approximate Dry Weight: | 390 lbs (178 kg) |
Features + Benefits
- Four cycle, 3 cylinder, liquid cooled, naturally aspirated, overhead valve, industrial-duty diesel.
- Swirl combustion design improves fuel efficiency, reduces smoke and noise.
- Glow plugs for fast cold weather starting.
- Liquid-cooled with radiator and pusher cooling fan. Steel radiator shroud and fan guard protects the radiator and operator.
- Bosch-type in-line injection pump.
- Stop solenoid controls the fuel rack, not throttle, to eliminate speed variance and linkage problems.
- Engine speed governed to 5% for close AC frequency control.
- Pintle fuel injectors have replaceable tips for lower service costs.
- Mechanical fuel pump with hand primer.
- Large spin-on fuel filter.
- Steel fuel lines.
- Large replaceable air filter protects engine in dusty environments.
- Residential muffler built into the exhaust manifold simplifies installation.
- Meets US EPA Tier IV exhaust emission requirements for cleaner air.
- Pressure lubricated. Trochoid oil pump.
- Full flow, spin-on oil filter with bypass.
- 3.1 qt. (3 ltr) oil capacity.
- 12 volt system includes starter motor, battery charging alternator with solid state voltage regulator and DC circuit breaker.
- Standard, unit mount S-1B control panel has engine hour meter, start-stop switch with run light and preheat switch.
- Dual panel relays and quick disconnect harness plug-ins. With optional Y-harness and 10, 20 or 40 foot wire harness extensions, you can have up to six remote control panels up to 100 feet from the generator set.
- Safety shutdown system for low oil pressure and high coolant temperature.
- Northern Lights, direct coupled, 4 pole, revolving fi eld, 4 lead reconnectable generator with Class H insulation and prelubricated bearing. Conservative heat rise rating: 95°C/50°C ambient. Compare this to light duty sets with heat rise ratings of 130°C or higher.
- External automatic voltage regulator gives you ±5% voltage regulation. AVR powered by dedicated AC winding for improved motor starting. AVR circuit breaker.
- 30 amp mainline circuit breaker protects generator from AC overloads and shorts.
- High air flow from integral fan keeps generator running cool.
- Welded steel skid frame gives rigid support and makes installation easy.
- Enhanced fan guard for improved operator safety.
- Flexible mounts isolate engine vibration for smooth operation.
- Long life, blue enamel paint finish.
- Operator’s and parts manuals.
- Rigorous quality control includes a test run with load.
- Export grade shipping crate protects set.
Note:
Information and dimensions are subject to change without notice.
Contact dealer for most current installation drawings
.
